What is CI? Continuous Integration Explained

Reading Time: 5 minutes

Continuous Integration (CI) is a software development practice that requires members of a team, to frequently integrate their code changes into a central repository (master branch), preferably several times a day.

Each merge is then verified by automatically generating a build, and running automated tests against that build.

By integrating regularly, you can detect errors quickly, as well as locate and fix them easier.

Why is Continuous Integration Needed?

Back in the days, BCI – Before Continuous Integration, developers from a single team might have worked in isolation for a longer period of time, and they merged their code changes only when they finished working on a particular feature or bug fix.

This caused the well-known merge hell (integration hell) or in other words a lot of code conflicts, bugs introduced, lots of time invested into the analysis, as well as frustrated developers and project managers.

All these ingredients made it harder to deliver updates and value to the customers on time.

How does Continuous Integration Work?

Continuous Integration as a software development practice entails two components: automation and cultural.

The cultural component focuses on the principle of frequent integrations of your code changes to the mainline of the central repository, using a version control system such as Git, Mercurial or Subversion.

But applying the cultural component you will drastically lower the frustrations and time wasted merging code, because, in reality, you are merging small changes all the time.

As a matter of fact, you can practice Continuous Integration using only this principle, but with adding the automation component into your CI process you can exploit the full potential of the Continuous Integration principle.

Continuous Integration Image
Source

As shown in the picture above, this includes a CI server that will generate builds automatically, run automated tests against those builds and notify (or alert) the team members of the results.

By leveraging the automation component you will immediately be aware of any errors, thus allowing the team to fix them fast and without too much time spent analysing.

There are plenty of CI tools out there that you can choose from, but the most common are: Jenkins, CircleCI, GitHub Actions, Bitbucket Pipelines etc.

Continuous Integration Best Practices and Benefits

Everyone should commit to the mainline daily

By doing frequent commits and integrations, developers let other developers know about the changes they’ve done, so passive communication is being maintained.

Other benefits that come with developers integrating multiple times a day:

  • integration hell is drastically reduced
  • conflicts are easily resolved as not much has changed in the meantime
  • errors are quickly detected

The builds should be automated and fast

Given the fact several integrations will be done daily, automating the CI Pipeline is crucial to improving developer productivity as it leads to less manual work and faster detection of errors and bugs.

Another important aspect of the automated build is optimising its execution speed and make it as fast as possible as this enables faster feedback and leads to more satisfied developers and customers.

Everyone should know what’s happening with the system

Given Continuous Integration is all about communication, a good practice is to inform each team member of the status of the repository.

In other words, whenever a merge is made, thus a build is triggered, each team member should be notified of the merge as well as the results of the build itself.

To notify all team members or stakeholders, use your imagination, though email is the most common channel, but you can leverage SMS, integrate your CI server with communication platforms like Slack, Microsoft Teams, Webex etc.

Test Driven Development

Test Driven Development (TDD) is a software development approach relying on the principle of writing tests before writing the actual code. What TDD offers as a value in general, is improved test coverage and an even better understanding of the system requirements.

But, put those together, Continuous Integration and TDD, and you will get a lot more trust and comfort in the CI Pipelines as every new feature or bug fix will be shipped with even better test coverage.

Test Driven Development also inspires a cultural change into the team and even the whole organisation, by motivating the developers to write even better and more robust test cases.

Pull requests and code review

A big portion of the software development teams nowadays, practice pull request and code review workflow.

A pull request is typically created whenever a developer is ready to merge new code changes into the mainline, making the pull request perfect for triggering the CI Pipeline.

Usually, additional manual approval is required after a successful build, where other developers review the new code, make suggestions and approve or deny the pull request. This final step brings additional value such as knowledge sharing and an additional layer of communication between the team members.

Summary

Building software solutions in a multi-developer team are as complex as it was five, ten or even twenty years ago if you are not using the right tools and exercise the right practices and principles, and Continuous Integration is definitely one of them.


I hope you enjoyed this article and you are not leaving empty-handed.
Feel free to leave a comment. 😀

Follow N47 on InstagramTwitterLinkedInFacebook for any updates.

iOS Unit Tests – My story

Reading Time: 5 minutes

In my last job interview – almost 2 years ago – I received a question about writing unit tests inside the iOS code. With the confidence of a developer with 8 years of experience in the iOS branch, my answer and my opinion at that moment were that if the developers are high-profiled and write good code writing unit tests is not necessary. Also, my answer continued with a conclusion: if the company has a testing team why do we (iOS developers) take their job? Throwing back on the answer and from today’s perspective, my feelings about the topic are mixed: First of all, I’ve learned more about the importance of the unit tests, and secondly, I’ve continued to work in an environment where we are not obligated to write tests.

Some basics

We should consider our code as pieces of code – called UNITS. The purpose of a unit test is to make validation of our code, and this will allow us to be sure that our code meets the design and fulfil the goal.

In XCode and iOS, the Unit tests are written in a separate target. The most important thing is the XCTest framework. The basic rule is that only the methods that start with the word test will be considered as unit tests by the compiler. Here is an example:

func testFormatForCard() {
    let formatter = DateFormatter()
    formatter.dateFormat = “ddMMyyyy”
    let date = formatter.date(from: “28061978")!
    XCTAssertEqual(date.formatForCard(), “28.06.1978”)
}

Once a test method is written with the proper semantic, the method is associated with rhombus sign on the left side:

Unit Tests with rhombus sign

We can run the tests to see if our code is good or if something is not working. If the test passes, the empty rhombus sign is changed with a green checkmark sign:

Figure 2: Test passed

In case of a failing test we have an assertion and a red sign:

Figure 3: Failed unit test

We can see in image 3 that intentionally the programmer entered the wrong output date 29.06.1978. That’s the way we should think when writing unit tests. First, we have to write the failing state and after that, we should enter the expected correct output. If in the second case the test passes, then we have created a useful unit test for that piece of code (unit). The general idea behind is if we change something in our code, and we made a mistake unintentionally the test should fail and warn us to fix the code.

Unit Test in practice

1. Code Coverage

There is a built-in option inside XCode for checking the code coverage of the tests. The ideal scenario is that 100% of our code is covered by unit tests. But is this really necessary? Will we be better programmers if our full code is supported with tests? Can we spend better the time we spent covering the tiniest pieces of code with proper tests?

In my opinion, writing unit tests is a philosophy and knowing the principles lead us to write qualitative code. That’s, of course, our goal as programmers. Covering the most important part of the code, especially the parts of code that are often changed like networking managers, parsers are a better option than trying to be perfect and writing 100% coverage.

2. Test Driven Development

The popular blog website for programmers Ray Wenderlich emphasizes the FIRST principles as a good way to follow writing unit tests. The basics of these principles are that the test should be fast, autonomous, repeatable, the output should be either “pass“ or “fail”, and ideally, the tests should be written before coding – Test Driven Development TDD.

The recommendation by TDD is writing tests before starting to fix a bug in the code. My opinion on this topic is also a mixing approach. Depending on the time you have, if the deadline is not close on the horizon, you can write tests before coding, or before starting to fix bugs in code, but that’s not always possible, and you won’t make a mistake if you skip this step sometimes.

Conclusion

I can say that writing unit tests is good for every programmer on his way to becoming great. The quality of coding could dramatically improve using unit tests. The philosophy of writing tests and thinking how the code should be structured to allow the tests to pass, will make you write cleaner code, better structured, using more protocols, make reusable classes… As in the strategy games, you shouldn’t always be a slave of the principles – the most important is to fulfill the goals in a quality manner. If you have enough time and not a strict deadline of the project you can make a bigger code coverage, but something around 75% is good enough.

Starting with unit testing using Vue.js 2 and Jest

Reading Time: 4 minutes

As a FrontEnd developer, you may know a lot of FrontEnd technologies and frameworks but in time you need to upgrade yourself as a developer. A good skill to strengthen your knowledge is to learn unit testing.

Since I am working with Vue.js for several years, we are going to see some of the basics for testing Vue components using the Jest JavaScript testing framework.

To start, first, we need a Vue.js 2 project created via the Vue CLI. After that we need to add the Jest framework to the project:

# jest unit testing
vue add @vue/unit-jest

I’ll make a simple component that will increase a number on click of a button:

// testComponent.js
export default {
  template: `
    <div>
      <span class="count">{{ count }}</span>
      <button @click="increase">Increase</button>
    </div>
  `,

  data() {
    return {
      count: 0
    }
  },

  methods: {
    increase () {
      this.count++
    }
  }
}

The way of testing is by mounting the components in isolation, after that comes the mocking the needed inputs like injections, props and user events. In the end, comes the confirmation of the outputs of the rendered results emitted events etc.

After that, the components are returned inside a wrapper. A wrapper is an object that contains a mounted component or a VNode and methods to test them.

Let’s create a wrapper using the mount method:

// jestTest.js

// first we import the mount method
import { mount } from '@/vue/test-utils'
import Calculate from './calculate'

// then we mount (wrap) the component
const wrapper = mount(Calculate)

// this way you can access the Vue instance
const vm = wrapper.vm

// you can inspect the wrapper by logging it into the console
console.log(wrapper)

Next step after we do the wrapping, follows to verify if the rendered HTML output of the component matches the expectations.

import { mount } from '@vue/test-utils'
import Calculate from './calculate'

describe('Calculate', () => {
  // Now mount the component and you have the wrapper
  const wrapper = mount(Calculate)

  it('renders the correct markup', () => {
    expect(wrapper.html()).toContain('<span class="calculate">0</span>')
  })

  // it's also easy to check for the existence of elements
  it('has a button', () => {
    expect(wrapper.contains('button')).toBe(true)
  })
})

Then run the tests with npm test and see them pass.

The code in testComponent.js should increment the number on button click so next step is to simulate the user interaction. For this, we need the wrapper’s method wrapper.find() to get the wrapper for the button and then simulate the click event by calling the method trigger().

it('simulation of button click should increment the calculate by 2', () => {
  expect(wrapper.vm.calculate).toBe(0)
  const button = wrapper.find('button')
  button.trigger('click')
  button.trigger('click')
  expect(wrapper.vm.calculate).toBe(2)
})

For asynchronous updates, we use the Vue.nextTick()(need to receive a function as a parameter) method, which comes from Vue. With this method, we are waiting for the DOM update and after that, we execute the code (the code in the function parameter).

// this will not be caught

it('time out', done => {
  Vue.nextTick(() => {
    expect(true).toBe(false)
    done()
  })
})


// the three following tests will work as expected
// (1)

it('catch the error using done method', done => {
  Vue.config.errorHandler = done
  Vue.nextTick(() => {
    expect(true).toBe(false)
    done()
  })
})

// (2)
it('catch the error using a promise', () => {
  return Vue.nextTick()
    .then(function() {
      expect(true).toBe(false)
    })
})

it('catch the error using async/await', async () => {
  await Vue.nextTick()
  expect(true).toBe(false)
})

Using nextTick can be tricky for the errors because the errors thrown inside it might not be caught by the test runner. That is happening as a consequence of using promises internally. To fix this we can set the done callback as a Vue’s global error handler (1) or we can use the nextTick method without parameter and return it as a promise (2) like we did earlier.

This article is a guide on how to set up the environment and start writing unit tests using Jest. For more information about testing with Vue and using Jest, you can visit the official site for Vue test utils.
